Technical Specifications
MODEL NO. 'ACE' | 40-5 | 50-5 | 60-5 | 75-5 | 90-5 | 100-5 | 105-5 | 120-4 | 150-3 | 180-3 | |
Basket Diameter | MM | 400 | 500 | 600 | 750 | 900 | 1000 | 1050 | 1200 | 1500 | 1800 |
Basket Mouth Diameter | MM | 300 | 370 | 425 | 550 | 650 | 700 | 750 | 850 | 1100 | 1200 |
Height of Basket Shell | MM | 250 | 250 | 325 | 325 | 450 | 450 | 450 | 450 | 500 | 600 |
Rated Charge in Basket | KG | 15 | 25 | 45 | 75 | 175 | 200 | 220 | 300 | 500 | 1000 |
Max.Cake Capacity of Basket | LTR | 13 | 22 | 44 | 64 | 136 | 175 | 190 | 256 | 384 | 847 |
Filter Area of Basket | SQ.M. | 0.31 | 0.39 | 0.62 | 0.77 | 1.29 | 1.41 | 1.48 | 1.71 | 2.38 | 3.39 |
Basket Speed | RPM | 1500 | 1350 | 1220 | 1100 | 1000 | 950 | 875 | 775 | 600 | 635 |
Acceleration a Basket | "G" UNIT | 503 | 509 | 499 | 507 | 503 | 500 | 449 | 403 | 302 | 403 |
Power of Motor | HP | 1 | 2 | 3 | 5 | 7.5 | 7.5 | 10 | 15 | 20 | 30 |
KW | 0.75 | 1.50 | 2.20 | 3.70 | 5.50 | 5.50 | 7.50 | 11.00 | 15.00 | 22.5 | |
Machine Area (Approx.) | MT | 0.8x1.0 | 1x1.2 | 1.2x1.5 | 1.5x1.7 | 1.7x1.9 | 1.9x2.2 | 2.0x2.2 | 2.2x2.5 | 2.5x2.8 | 3x3.5 |
Machine Weight (Approx.) | KG | 550 | 650 | 950 | 1150 | 1600 | 1700 | 1800 | 2200 | 3000 | 4000 |
